CPU Processor

RK3288 / Quad-Core 1.6 GHz

RAM

2GB

EMMC

8 GB (16 GB / 64 GB Optional)

GPU

ARM Mali-T764

Screen Size

10.1 in

Brightness

450cd/m2

Resolution

800*1280

Viewing Angle

Wide-Viewing-Angle IPS

Touch Type

3-Point Capacitive Touch

GPU

ARM Mali-T764

Overall Dimensions

256 × 170 × 34 mm; Weight approx. 1.05 kg

Electrostatic Discharge (ESD)

GB/T 17626.2-2018 Level 3

Electrical Fast Transient (EFT)

GB/T 17626.4-2018 Level 3

Surge

GB/T 17626.5-2019 Level 3

Power-Frequency Magnetic Field (PFMF)

GB/T 17626.8-2006 Level 5

Serial Ports

4 × RS232, 2 × RS485 (2 RS485 Ports Multiplexed with RS232)

USB

4 × USB Host, USB Device

Audio

1 × Mono MIC, 1 × Stereo SPK

HDMI

1 × HDMI 2.0 Interface

Ethernet

1 × 10/100 Mbps Auto-Negotiation Ethernet Interface

GPIO

4 × Bidirectional I/O, 3.3 V Logic

SIM Card

1 × Standard SIM Card

TF

1 × TF Card Interface

LED

1 Power Indicator, 1 System Indicator

Power

1 × DC 12 V ±5% / DC 24 V ±5%

Key

1 × Programming/Back Key

SIM Card

1 × Standard SIM Card
